High Quality PCB Production

At Azitech we have cooperation’s  with factories across Asia and Europe and we can help with both simple and complex printed circuit board productions up to 76 layers.

Design Center

Our Design Center is your new PCB Ressource hub with vast information for you to download.

Request a Quote

Send us a message for a free consultation and custom quote for your next PCB challenge.

DFM Analysis

Our free DFM analysis will check your files from 40 critical design rules.

We Are Experts In Sample And Mass PCB Productions

PCB Production

Azitech has cooperated with factories in Asia and Europe for several years. Our suppliers in Europe can help with both simple and complex printed circuit board productions up to 72 layers.

Mass Production

At Azitech, we are used to running both prototypes and series production. We are your partner during the entire process, and guide your PCB project from the design phase through to mass production.

Storage

By using Azitech’s storage service in the Scandinavia, it will be possible to have immediate deliveries. Our warehouse is ESD secured and all printed circuit boards are stored vacuum packed.

Delivery Time

Delivery time from our warehouse to anywhere in Europe is usually 1-2 days. The price for storage is 3% of the total delivery price for each month started.

We have Rogers on stock in China, we can deliver these to the factories within 1-2 days. However, we require you to make an agreement with us as a customer, before we store the material so that you can start production quickly.

Laboratory

Azitech’s own laboratory in Denmark, with the option of quality checking your printed circuit board.

  • Visual inspection service
  • Tape test
  • ESD handling
  • Vacuum packing

Production Capabilities

Rigid: up to 76 layers

Rigid Flex: up to 36 layer 50 µm line and space, 50 µm laser micro via, minimum dielectric 12 µm

Flex: up to 12 layers

HDI Type 1, 2, 3 & 4

Aluminum boards, Hybrid Power PCB, Heavy copper Boards, SBU HDI Boards

Fine lines: down to 0,03 mm

SM Bridges: down to 0,075 mm

Aspect Ratio: 21:1 (PTH)

Ultra Thick Copper: 200-500 µm

Copper Inlay PCB

Surface Finishes

Advantages of OSP / ENTEK

  • Flat Surface
  • Cheap
  • Simple Process
  • Re-workable
  • Environmental friendly

Disadvantages of OSP / ENTEK

  • No Way to Measure Thickness
  • Not Good for PTH (Plated Through Holes)
  • Short Shelf Life
  • Can Cause ICT Issues
  • Exposed Cu on Final Assembly
  • Handling Sensitive

Advantages of ENIG

  • Flat Surface
  • No Pb
  • Good for PTH (Plated Through Holes)
  • Long Shelf Life

Disadvantages of ENIG

  • Expensive
  • Not Re-workable
  • Black Pad / Black Nickel can occurs
  • Damage from ET
  • Signal Loss (RF)
  • Complicated Process

Advantages of IMMERSION SILVER

  • Plane surface makes it ideal for finepitches
  • Environmentally better than ENIG and HASL
  • Shelf life equal to HASL
  • Cheaper than ENIG
  • Fine for ALU bonding
  • Stronger solder joint than ENIG
  • Good for EMS shielding

Disadvantages of IMMERSION SILVER

  • Must be soldered within the day the PCB is removed from storage
  • Can be tarnished easily with improper handling
  • Less durable than ENIG due to no layer of nickel underneath

Advantages of ENEPIG

  • Extremely Flat Surface
  • No Lead Content
  • Multi-Cycle Assembly
  • Excellent Solder Joints
  • Wire Bondable
  • No Corrosion Risks
  • 12 Month or Greater Shelf Life
  • No Black Pad Risk

Disadvantages of ENEPIG

  • Still Somewhat More Expensive
  • Is Re-Workable with Some Limitations
  • Processing Limits

Advantages of LF HASL

  • Low Cost
  • Widely Available
  • Re-workable
  • Excellent Shelf Life

Disadvantages of LF HASL

  • Uneven Surfaces
  • Not Good for Fine Pitch
  • Contains Lead (HASL)
  • Thermal Shock
  • Solder Bridging
  • Plugged or Reduced PTH’s (Plated Through Holes)
